Technical Guidance
Over 40 years of practical engineering, built on reliability, experience and long-term relationships.
- ISO 9001 Certified
- Manufactured to Industry Standards
- Family-Run & Established 1984
Swipe sideways to view full table on mobile.
| Work Type | Typical Services | Quantity / Scope | Typical Lead Time | Notes |
|---|---|---|---|---|
| Urgent Local Support | Modifications & Repairs, Precision Engineering, CNC Milling, CNC Turning | Usually 1–5 parts | From 24 hours* | For urgent local jobs where material is available and the work is straightforward. Contact IJF as early as possible to discuss. |
| Prototype / One-Off Parts | Prototype Machining, Bespoke Machinery, Component Development, CAD/CAM Support | 1–5 parts | 1–2 weeks | Depends on complexity, material, design input and whether testing or development is required. |
| Small Batch Machining | CNC Milling, CNC Turning, Batch Production, Precision Engineering | 6–25 parts | 1–4 weeks | Suitable for repeat parts, replacement components or low-volume production runs. |
| Bespoke Machinery / Assembly Work | Bespoke Machinery, Fabrication, Finishing & Assembly | Project-dependent | Quoted per project | Lead time depends on design, manufacture, assembly, testing, installation and commissioning requirements. |
| Ongoing / Repeat Supply | Batch Production, CNC Milling, CNC Turning, Finishing & Assembly | Small batch / scheduled supply | Agreed schedule | Best suited to customers who need repeat parts, call-off supply or planned production support. |
*Lead times are indicative and depend on material availability, complexity, capacity and approval times. Urgent work is assessed on a case-by-case basis.
Swipe sideways to view full table on mobile.
| Process | Max Dimensions / Capacity | Notes |
|---|---|---|
| Manual Milling | Approx. 2m x 1m x 1m | Conventional milling capacity for components too large for CNC milling machines. |
| Manual Horizontal Milling | Approx. 1500mm x 400mm bed travel | Used for larger horizontal milling work and components requiring manual machining. |
| Manual Vertical Milling | Approx. 1300mm x 500mm x 450mm bed travel | Used for larger vertical milling work across a range of component sizes. |
| CNC Lathe | Up to 480mm swing over bed x 2m bed length | Suitable for accurate turned components and small batch production. |
| Manual Lathes | Up to 600mm swing over bed x 3m bed length | Used for larger turned components beyond CNC lathe capacity. |
| Horizontal Boring | Up to 300mm bore depth | Suitable for larger components requiring accurate boring operations. |
| Drilling | 600mm arm radial drilling capacity | Used for drilling operations on larger or awkward components. |
| Slotting | Up to 400mm stroke | Mainly used for cutting internal keyways. |
| Surface Grinding | 700mm x 250mm bed size | Used for flat and angled components requiring a controlled finish. |
| MIG/TIG/Stick Welding | Fabricated structures up to approx. 10m length | Supported by overhead gantry crane. Suitable for mild steel and stainless steel fabrication. |
| Spark Erosion | Small component detail work | Used for difficult detail, conductive materials and profiles not achievable through standard machining. |
Maximum dimensions are provided as a guide only. Capacity depends on component shape, weight, material, access, setup and the machining process required. For larger or unusual components, IJF can advise once drawings or sample parts have been reviewed.
Swipe sideways to view full table on mobile.
| Process | Typical Tolerance Capability | Notes |
|---|---|---|
| CNC Milling | Drawing-led tolerances | Suitable for accurate, repeatable components. Final tolerance depends on geometry, material and setup. |
| CNC Turning | Drawing-led tolerances | Well suited for components requiring consistent diameters, concentricity and repeatability. |
| Surface Grinding | Tight tolerance finishing | Used where improved flatness, parallelism or surface finish is required. |
| Manual Milling | Standard engineering tolerances | Used for larger components or work outside CNC capacity. Tolerances depend on setup and part size. |
| Manual Turning | Standard engineering tolerances | Suitable for larger turned components beyond CNC capacity. Accuracy depends on size and machining approach. |
| Spark Erosion | High-detail precision machining | Used for conductive materials and intricate internal features not achievable through conventional machining. |
| Slotting / Keyway Cutting | Fit-for-purpose tolerances | Tolerances depend on keyway size, fit requirements and mating components. |
| Fabrication / Welding | Fabrication tolerances | Influenced by material type, weld process, distortion control and final application. |
Tolerances are defined by the component drawing and application requirements. Final achievable tolerances depend on material, geometry, size and the machining or fabrication process used. Specific requirements should be confirmed at enquiry stage.
Swipe sideways to view full table on mobile.
| Finishing Process | Purpose | Additional Information |
|---|---|---|
| Hard Anodising | Creates a durable oxide layer on aluminium to improve wear and corrosion resistance. | Typically 25–30 microns thick. Commonly used for external or high-wear components. May require masking and machining allowance depending on the part. |
| Sulphuric Anodising | Applies a thin decorative finish to aluminium components. | Usually less than 5 microns thick. Primarily for appearance with limited protective benefit. |
| Bead Blasting | Produces a consistent matte surface by removing machining marks. | Improves visual uniformity and reduces surface reflectivity. Often used prior to further finishing. |
| Powder Coating | Applies a robust, coloured coating for protection and durability. | Provides a tough, wear-resistant finish. Common for brackets, enclosures and external components. |
| Chromate Conversion Coating | Improves corrosion resistance while maintaining electrical conductivity. | Typically used on aluminium parts in electrical or electronic applications. Also known as chemical film or conversion coating. |
| Polishing | Refines the surface to achieve a smooth or high-quality finish. | Used where surface condition is critical, whether for appearance or performance. |
| Nickel Plating | Adds a protective metallic layer to improve wear and corrosion resistance. | Provides a uniform finish with moderate hardness. Can also be used for aesthetic purposes. |
| Zinc Plating | Protects steel components from corrosion by applying a zinc layer. | Often finished with clear, yellow or black passivation. A cost-effective solution for general protection. |
| Burnishing | Improves surface finish and strengthens the material through deformation. | Creates a smooth surface without removing material. Can improve fatigue performance and appearance. |
| Ultrasonic Cleaning | Removes contaminants such as oils, swarf and fine particles. | Uses high-frequency cleaning to reach complex geometries and internal features. Leaves components clean and residue-free. |
| Assembly | Combines individual components into a complete or part-complete unit. | May include fasteners, inserts, press fits or sub-assemblies to streamline installation and use. |
Finishing processes are selected based on the material, application and performance requirements of each component. Where specific finishes, coatings or surface treatments are required, these should be detailed at enquiry stage.
Our Process
From enquiry to delivery, a process that works.
01 — Understanding your requirement
We start by understanding exactly what you need, drawings, timelines, materials and any constraints so nothing is missed upfront.
02 — Clear, practical quoting
You’ll receive a straightforward quote based on the most efficient way to manufacture your part, no unnecessary complexity.
03 — Planning & preparation
We review the job in detail and work closely with the client to ensure everything is set up for accuracy, efficiency and a smooth run.
04 — Machining & production
Your components are manufactured using the most appropriate processes, with a focus on quality, consistency and lead time.
05 — Inspection & finishing
Parts are checked throughout production and on completion to ensure they meet specification & our high standards before leaving us.
06 — Delivery & ongoing support
We deliver on time and remain available for any follow-up, repeat work or future projects.
